Product Detail

Seasonic Focus SGX650 650watts 80+ Gold semi modular

Quick Overview
80PLUS® Gold Cybenetics Efficiency Level ETA-A (View report) Cybenetics Noise Level LAMBDA-S+ (View report) Form Factor Intel SFX 12 V / ATX 12 V Dimensions 125 mm (L) x 125...


Sold Out

  • 80PLUS® Gold
  • Cybenetics Efficiency Level ETA-A (View report)
  • Cybenetics Noise Level LAMBDA-S+ (View report)
  • Form Factor Intel SFX 12 V / ATX 12 V
  • Dimensions 125 mm (L) x 125 mm (W) x 63.5 mm (H)
  • Fan Information Fan Size 120 mm
  • Fan Control Premium Hybrid Fan Control
  • Fan Bearing Fluid Dynamic Bearing
  • Life Expectancy 50,000 hours at 40 °C, 15 % - 65 % RH
  • Cable Information Modularity Fully Modular
  • Cable type Flat black cables
  • Electrical Features Operating Temperature 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
  • MTBF @ 25 °C, excl. fan 100,000 hours
  • AC Input Full Range
  • Protection OPP, OVP, UVP, OCP, OTP, SCP
  • Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, CE
  • Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
  • Power Output
  • AC Input Voltage: 100 V - 240 V
  • Current: 9 - 4.5 A
  • Frequency: 50 Hz - 60 Hz
  • DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
  • Maximum Power 20 A 20 A 54 A 0.3 A 3 A
  • 100 W 648 W 3.6 W 15 W
  • Total continuous power 650 W
  • Cable type Connector(s) per cable Total length (mm) Number(s) of cable(s) included
  • MB-610 MB (24/20 pins) 1 350 1
  • CPU-650 CPU (8/4 pins) 1 400 1
  • PCIe-750-2x PCIe (8/6 pins) 2 500 2
  • SATA-600-3x-90 SATA 3 600 2
  • Molex-690-3x Molex 3 700 1
